Anonymised project example
6-tonne welding fixture — fully manufactured by Fritech
A complete tool was manufactured to customer documentation, including parts, welded frame, machining, assembly and painting. The documentation defined multiple loading and welding stages. Customer name, drawing numbers and product geometry are not published.
Examples of manufactured components
Bent tube components
- Task
- Prepare tube components for subsequent assembly.
- Fritech scope
- Manufacture bent tube components.
- Material
- Stainless steel.
- Scale
- A series of components shown in the gallery.
Steel plates with holes
- Task
- Prepare plates for further production.
- Fritech scope
- Cut plates and openings to documentation.
- Material
- Steel.
- Scale
- A bundled batch of plates prepared for transport.
Corten planters — our projects
Manufacturing to customer documentation
Production tooling, welded structures, components, CNC machining, stainless steel and assemblies prepared for transport.
Only materials approved for publication are shown. Customer data and identifying markings are removed or obscured.Projects
Complex tooling and structures without exposing customer know-how
A significant part of our work is based on confidential customer documentation. We therefore present the scope, scale and Fritech responsibility, while visual material is published only after anonymisation and approval.
Typical scope
What a complete delivery can include
Production tooling
Frames, bases, clamps, locating elements and mechanical interfaces to process equipment.
→Welded structures
Large frames, bases, industrial platforms and assemblies prepared for further installation.
→Post-weld machining
Machining of datums, mounting faces and areas requiring precise relative positioning.
→Assembly and acceptance
Adjustment, measurement, agreed protocol, transport and commissioning support.
→Confidentiality
How we prepare projects for safe publication
Marketing material must not disclose design solutions or information belonging to the customer.
- removal of logos, customer names and drawing numbers
- concealment of distinctive product or component geometry
- reduction of dimensions and parameters to a safe level of generality
- publication only of approved photographs, visualisations or crops
- clear description of Fritech responsibility without claiming the customer's design
- more detailed presentation of comparable scope after an NDA is in place
Project gallery
The portfolio grows as suitable material is approved
The absence of a public photograph does not mean a lack of experience. For an enquiry, we select the closest safe example and discuss the scope without breaching obligations to previous customers.
